NJM4580M

NJM4580M, dual operational amplifier, SOP, ±18V, ±50mA, 800mW, Japan Radio

Rated 5 Rating 5 | reviews | Write a review

Price:: US $1.50~2.00 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
1 ~ 300 :	2.00 / Piece
301 ~ 600 :	1.80 / Piece
601 ~ 1000 :	1.50 / Piece

PartNumber:: NJM4580M

Brand:: Japan Radio Co.,ltd - JRC | Pack: SOP | D/C: 11+

Availability:: Supply Ability: 1000/Day Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Not exactly what you want? Post a quick Buying Request!

Sold By

Ms. Alice's store

(China (Mainland))

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2013-04-10

From Other Seller

Part Number:NJM4580M
US $1.50 - 2.00
Quantity:

piece

Product Summary

The NJM4580M is a dual operational amplifier, specially designed for improving the tone control, which is most suitable for the audio application. Featuring noiseless, higher gain bandwidth, high output current and low distortion ratio, and it is most suitable not only for acoustic electronic parts of audio pre-amp and active filter, but also for the industrial measurement tools.

Parametrics

NJM4580M absolute maximum ratings: (1)Supply voltage, V+/V-: ±18V; (2)Input voltage, VIC: ±15V; (3)Differential input voltage, VID: ±30V; (4)Output current, ID: ±50mA; (5)Power dissipation, PD: 800mW; (6)Operating temperature range, Topr: -40 to 85℃; (7)Storage temperature range, Tstg: -40 to 125℃.

Features

NJM4580M features: (1)Operating voltage: ±2V to ±18V; (2)Low input noise voltage: 0.8μVrms typ; (3)Wide gain bandwidth product: 15MHz typ; (4)Low distortion: 0.0005% typ; (5)Slew rate: 5V/μs typ; (6)Package outline: DIP8, SIP8, EMP8, SSOP8, DMP8; (7)Bopolar technology.
