Product Summary
The PLRXPL-VC-SH4-23-N is a lead-free and RoHS-compliant small form factor pluggable (SFP+) transceiver from JDSU improves the performance for 8 Gigabit Fibre Channel (8G FC) applications, and is ideal for high-speed, storage area network applications. This transceiver features a highly reliable, 850 nm, oxide, vertical-cavity surfaceemitting laser (VCSEL) coupled to an LC optical connector. The transceiver is fully compliant to the 8 G FC, FC-PI-4, and the SFP+ multisource agreement(MSA) specifi cations, with internal AC coupling on both transmit and receive data signals. The applications of the PLRXPL-VC-SH4-23-N include High-speed storage area networks, Switches and hubs, Network interface cards, Mass storage systems, Host bus adapters, Computer cluster crossconnect systems, Custom high-bandwidth data pipes.
Parametrics
PLRXPL-VC-SH4-23-N absolute maximum ratings: (1)Storage temperature, Tst: -40 to +95℃; (2)Operating case temperature, Tc: -40 to +90℃; (3)Power supply voltage, Vcc: 0 to +4.0 V; (4)Transmitter differential input voltage, VD: 2.5 VP-P; (5)Relative humidity, RH: 5 to 95 %.
Features
PLRXPL-VC-SH4-23-N features: (1)Compliant to industry-wide, 8 G Fibre Channel (FC) link specifi cations; (2)Maintains FC compliance at 4 and 2 G without need for a rate select option; (3)Uses a highly reliable, 850 nm oxide VCSEL; (4)Lead-free and RoHS 6/6-compliant; (5)0 to 70℃ case operating temperature; (6)Single 3.3 V power supply; (7)Low power consumption (typically 450 mW); (8)Bit error rate < 1 x 10-12; (9)Hot pluggable.
Diagrams
