Product Summary

The PLRXPL-VE-SG4-62-N is a lead-free and RoHS-compliant multi-rate Small Form Factor Pluggable (SFP) transceiver provides superior performance for Fibre Channel applications, and is another in JDSU’s family of products customized for high speed, short reach SAN, and intra-POP applications. The multi-rate feature enables its use in a wider range of system applications. The applications of the PLRXPL-VE-SG4-62-N include High-speed storage area networks, Switch and hub interconnect, Mass storage systems interconnect, Host adapter interconnect, Computer cluster cross-connect, Custom high-speed data pipes.

Parametrics

PLRXPL-VE-SG4-62-N absolute maximum ratings: (1)Storage temperature, Tst: -40 to +95℃; (2)Operating case temperature, Tc: -20 to +85℃; (3)Power supply voltage, Vcc: 0 to +4.0 VP-P; (4)Transmitter differential input voltage, VD: 2.5 V; (5)Relative humidity, RH: 5 to 95 %.

Features

PLRXPL-VE-SG4-62-N features: (1)Compliant with industry-wide physical and optical specifi cations; (2)Lead-free and RoHS-compliant; (3)Superior EMI peformance; (4)Cost effective SFP solution; (5)Triple-rate FC performance; (6)Enables higher port densities; (7)Enables greater bandwidth; (8)Proven high reliability; (9)In-house precision alignment.

Diagrams

PLRXPL-VE-SG4-62-N block diagram
