Product Summary
The SN74ACT14PW is a schmitt-trigger inverter. The SN74ACT14PW contains six independent inverters. The SN74ACT14PW is temperature compensated and can be triggered from the slowest of input ramps and still gives
clean, jitter-free output signals. The SN74ACT14PW also has a greater noise margin than conventional inverters.
Parametrics
SN74ACT14PW absolute maximum ratings: (1) Supply voltage range, VCC: -0.5 to 7V; (2) Input voltage range, VI: -0.5 V to VCC + 0.5 V; (3) Output voltage range, VO: -0.5 V to VCC + 0.5 V; (4) Input clamp current, IIK(VI< 0 or VI> VCC) : ±20mA; (5) Output clamp current, IOK (VO< 0 or VO> VCC) : ±20mA; (6) Continuous output current, IO (VO= 0 to VCC) : ±50mA; (7) Continuous current through VCC or GND: ±200mA; (8) Storage temperature range, Tstg: -65°C to 150 °C.
Features
SN74ACT14PW features: (1) 4.5-V to 5.5-V VCC Operation; (2) Max tpd of 11ns at 5V; (3) Inputs Are TTL-Voltage Compatible.
Diagrams
