24AA64F-I/ST

24AA64F-I/ST, prom memory, 6.5 v, 500 μa, 100 khz, bga

Rated 5 Rating 5 | reviews | Write a review

Price:: US $3.00~5.00 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
1 ~ 100 :	5.00 / Piece
101 ~ 1000 :	4.00 / Piece
1001 ~ 10000 :	3.00 / Piece

PartNumber:: 24AA64F-I/ST

Brand:: Microchip Technology - Microchip | Pack: BGA | D/C: 11+

Availability:: Supply Ability: 10000/Day Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Not exactly what you want? Post a quick Buying Request!

Sold By

Ms. Alice's store

(China (Mainland))

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2013-08-26

From Other Seller

Part Number:24AA64F-I/ST
US $3.00 - 5.00
Quantity:

piece

Product Summary

The 24AA64F-I/ST is a 64kbit electrically erasable PROM memory organized as 8k x 8 with a 2-wire serial interface. Low-voltage design permits operation down to 1.7 volts for the 24AA00 version, and every version maintains a maximum standby current of only 1 μA and typical active current of only 400 μA. The 24AA64F-I/ST was designed for where a small amount of EEPROM is needed for the storage of calibration values, ID numbers or manufacturing information, etc. The 24AA64F-I/ST is available in 8-pin PDIP, 8-pin SOIC (3.90 mm), 8-pin TSSOP, 8-pin 2x3 DFN and the 5-pin SOT-23 package.

Parametrics

24AA64F-I/ST absolute maximum ratings: (1)VCC: 6.5 V; (2)All inputs and outputs w.r.t. VSS: -0.6 V to VCC +1.0 V; (3)Storage temperature: -65 °C to +150 °C; (4)Ambient temperature with power applied: -40 °C to +125 °C; (5)ESD protection on all pins: 4 kV.

Features

24AA64F-I/ST features: (1)Single-Supply with Operation down to 1.7V for 24AA64F devices, 2.5V for 24LC64F devices; (2)Low-Power CMOS Technology: Read current 400 μA, max; Standby current 1 μA, max. (I-temp).; (3)2-Wire Serial Interface, I2C™ Compatible; (4)Packages with 3 Address Pins are cascadable up to 8 Devices; (5)Schmitt Trigger Inputs for Noise Suppression; (6)Output Slope Control to Eliminate Ground Bounce; (7)100 kHz and 400 kHz Clock Compatibility; (8)Page Write Time 5 ms, typical; (9)Self-timed Erase/Write Cycle; (10)32-Byte Page Write Buffer; (11)Hardware Write-protect for 1/4 Array (1800h-1FFFh); (12)ESD Protection > 4,000V; (13)More than 1 Million Erase/Write Cycles; (14)Data Retention > 200 Years; (15)Factory Programming Available; (16)Packages include 8-lead PDIP, SOIC, TSSOP,; (17)MSOP, TDFN, 5-lead SOT-23; (18)Pb-Free and RoHS Compliant; (19)Temperature Ranges: Industrial (I): -40°C to +85°C; Automotive (E): -40°C to +125°C.
