Product Summary
The SY100EL32VZG is an integrated ÷2 divider. The differential clock inputs and the VBB allow a differential, single-ended or AC-coupled interface to the device. If used, the VBB output should be bypassed to ground with a 0.01μF capacitor. Also note that the VBB is designed to be used as an input bias on the SY100EL32VZG only; the VBB output has limited current sink and source capability.
Parametrics
SY100EL32VZG absolute maximum ratings: (1)fMAX, Maximum Toggle Frequency: 2.6 to 3.0GHz; (2)tPD, Prop Delay to Output D Reset to Q: 420 to 600ps; (3)VPP, Minimum Input Swing: 150mV; (4)VCMR, Common Mode Range: -0.4 to -1.4V; (5)tr,tf, Output Rise/Fall Times Q (20% to 80%): 100 to 350ps.
Features
SY100EL32VZG features: (1)3.3V and 5V power supply options; (2)510ps propagation delay; (3)3.0GHz toggle frequency; (4)High bandwidth output transistions; (5)Internal 75KΩ input pull-down resistors; (6)Available in 8-pin SOIC package.
Diagrams
| Image | Part No | Mfg | Description |  |
Pricing (USD) |
Quantity | ||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|
 |
 SY100EL32VZG |
|
IC DIVIDER X2 5V/3.3V 8SOIC |
Data Sheet |
|
|
||||||
|
SY100EL32VZG TR |
|
IC DIVIDER X2 3.3/5V 8SOIC |
Data Sheet |
|
|
||||||
